Model – Description |
EPL-100-12VLITE |
Nominal Voltage |
12.8V |
Nominal Capacity |
100Ah |
Cycle Life (DOD – 80% under controlled conditions) |
≥ 2000 Cycles |
Standard Charge Specification (Lithium profile charger required) |
Battery Charge Temperature |
0 ̴ 45°C |
Normal Charge Voltage CV/CC* |
14.20 ̴ 14.60V |
Standby (Float) Voltage |
13.50 ̴ 13.60V |
Maximum Charge Current |
80A @ 25°C for 30mins |
Recommended Charge Current for Maximum Life |
≤33A |
Standard Discharge Specification |
Battery Discharge Temperature |
-20 ̴ 60°C |
Battery Output Voltage Range |
11.00 ̴ 14.60V |
Maximum Discharge Current |
100A @ 25°C ± 5°C for 30mins |
Pulse Discharge Current |
450A for 1.0s |
Discharge Cut-off Voltage |
≤11.20V |
Over-Charge Protection |
Over-charge Protection Per Cell |
3.90V ± 0.03V |
Over-charge Release Per Cell |
3.60V ± 0.05V |
Over-charge Release Method |
Discharge below release voltage |
Over-Discharge Protection |
Over-discharge Protection Per Cell |
2.50V ± 0.05V |
Over-discharge Release Per Cell |
3.20V ± 0.05V |
Over-discharge Release Method |
Apply Charge/Voltage ≥12.8V |
Battery Manual Reset Button |
No |
Over Current Protection |
Discharge Over Current |
110A for 30s – 450A for 1s |
Protection Reset Time |
5s Auto Release |
Over Current Release Method |
Disconnect Load |
Over Temperature Protection |
Battery Discharge Over Temperature |
Protection to 65°C ± 5°C
Release at 50°C ± 5°C
|
Battery Charge Over Temperature |
Protection to 55°C ± 5°C
Release at 45°C ± 5°C
|
Short Circuit Protection |
Auto release after 5s |
Mechanical Characteristics |
Dimensions |
310mmx170mmx225mm |
Weight |
Approx 12kg |
Storage Information |
Temperature & Humidity Range |
≤ 30 days -20°C ̴ 35°C, 45 ̴ 75% RH
≥ 30 days -10°C ̴ 30°C, 45 ̴ 75% RH
|
Self-discharge Rate |
≤ 3% Per Month |
